Environment
Using false air reduction method to reduce carbon footprint
Published
5 years agoon
By
admin
In the present environment due to the energy crisis and steep increase in the cost of energy and other input materials, it has become imperative to give a serious thought on how to make operations and equipment efficient towards use of energy and adopting latest technology equipment to retain the requisite competitive edge in the market, discusses KK Sharma of Invotech Industrial Solutions.
India was the second largest cement producer in the world in terms of cement capacity during 2019. Therefore, one can easily assume the amount of energy being consumed in cement production facilities and its wastage attributed to non-availability of proper technology to plug the leakages. We can find hundreds of research papers/case studies discussing the effect of different factors on energy consumption in cement manufacturing facilities. Some researchers also discuss this issue with the help of mathematical models. However, all the researchers more or less agree to the fact that "false air" not only but may be one of the factor of more energy consumption in cement industry. Further, based on the several studies in the field of operational audit, it can be concluded that production level can be improved and energy consumption reduced by reduction of "false air".
What is false air
False air is any unwanted air entering into the process system. The exact amount of false air is difficult to measure. However, an indicator of false air can be, increase of % of oxygen between two points (usable for gas stream containing less than 21 per cent of oxygen). Due to unwanted air, the power consumption increases and system’s temperature decreases. Therefore, to maintain the same temperature fuel consumption has to be increased.
Impact of false air in cement plant:
- Increase of power consumption
- Increase the fuel consumption
- Unstable operation
- Reduction in productivity
- Higher wear of fans
False air intrusion points
In cement sector, generally false air intrudes in kiln section through kiln outlet, inlet seal, TAD slide gate, inspection doors and flap box. Similarly, in mill section false air intrudes through rotary feeder at mill inlet, mill body, mill door, flaps, expansion joints, holes of ducts and tie rod entry point.
In power sector, as margin is very less, cost- effectiveness plays an important role. Generally false air intrudes in CPP section through air pre-heater casing, boiler main door, fan casing, inspection doors, ESP main doors, ESP hopper doors, expansion bellows andducts. Similarly, in GPP section false air intrudes through main holes, hammering, bellows, rotary air locks, damper casing, expansion bellow, etc.
How to measure false air The formula used for measuring false air as under:
Atmospheric air normally has a content of zero per cent CO and 20.99 per cent O2. How to measure false air across pre-heater and mill: Based on the oxygen content and flow measurement at particular location, we can find out amount of false air across the pre-heater and mill circuit. For this purpose, % of O2 is measured at different locations, i.e.,pre-heater inlet and outlet, cyclone inlet and outlet, mill inlet and outlet, mill outlet to fan inlet, across bag-house or ESP.
False air detection through ultrasonic leak detector: Ultrasonic leak detectors often called sniffer, especially designed to find small leaks, are also being used in enclosed gas systems.Since ultrasonic gas detectors search for the sounds of leaks rather than escaping gases, they are able to detect leaks of any gas type. Though the device is unable to measure gas concentration, it is able to determine the leak rate of an escaping gas because the ultrasonic sound level depends on the gas pressure and size of the leak.
Functioning of ultrasonic leak detector: When gas escapes a pressurised line, it generates a sound in the range of 25 kHz to 10 MHz, well above the frequencies, the human ear is sensitive to but in a range easily identifiable to ultrasonic sensors. When the detector senses ultrasonic frequencies, they are isolated from normal background noise, amplified, and converted to a frequency audible to humans.
Detection principle: When a gas passes through a restricted orifice under pressure, it goes from a pressurised laminar flow to low pressure turbulent flow. The turbulence generates a broad spectrum of sound called ?white noise?. There are ultrasonic components in this white noise. Since the ultrasound is loudest at the leak site, it can be detected very easily.
False air arresting
Usually cement plants use conventional methods to arrest false air, but these conventional methods are not reliable or permanent in nature. In fact, it works more like a silencer and just after a few days it gets damaged.
Therefore, Invotech Solution & Systems, which is now Invotech Industrial Solutions, a Rajasthan-based company, have come up with a unique product range after their years of research, which are being used in many cement manufacturing facilities. The client list figures renowned names like JK Cement, Dalmia Bharat, Nirma Group (Nuvoco Vistas), UltraTech, India Cements, Sagar Cements, Jaypee Group , Chettinad Cement and many more in the pipeline.
Invotech Industrial Solutions provides innovative and cost-effective industrial solution for arresting false air in cement plants, i.e.,pyro-process, raw mill, coal mill, cement mill section and bag-house. The "Arrest Master" (Product Name) is user friendly and safe to use.
Product range: False Air Arresting Compound
Arrest Master 1001: For upper cyclones, VRMs and power plants, shell temperature resistant upto 180 degree Celsius
Arrest Master 1002: For bag-house and bag filters top doors
Arrest Master 1003: For high temperature zone upto 500 degree Celsius.
Arrest Master 1004: For high temperature zone upto 800 degree Celsius.
Arrest Master 2001: For areas having vibrations, Shell temperature resistant upto 180 degree Celsius.
Properties of Arrest Master- false air arresting compound: Application of ‘Arrest Master Series’ brings down the level of false air and it is useful in all cement and power plants.
It hugely impacts plant productivity and contributes towards better housekeeping.Its other characteristics are:
- Gets further strong with heat
- Once cured, Arrest Master becomes rock hard ensuring no leaks
- High compressive strength and impact resistant, which can only be removed by hammering
- Non shrinkable properties and no tools required for application
As a matter of fact, in 2018, Dalmia Cement Bharat acquired the former Kalyanpur Cements, Bihar, which is now Dalmia DSP, Banjari, Bihar. It was a dormant plant and was started after being stopped for more than 20 years, it got overhauled and upgraded. It was the only fully integrated cement plant in Bihar. Invotech Industrial Solutions carried out complete false air arresting work in above plant.After completion of work, 3.5 per cent of false air could be reduced.
Invotech Industrial Solutions keeps itself abreast of latest development in cement industry so as to cater the need of the Industry using latest technology and quality systems. Also, with a view to retain the requisite competitive edge in the market, participated in various seminars, details as under:
-
15th & 16th NCB International Seminar on cement, concrete & building materials held from December 5-8, 2017 and December 3-6, 2019 at Manekshaw Center, New Delhi.
-
National workshop-cum-technology exhibition to promote energy efficient and cleaner production for sustainable industrial growth held from March 8-9, 2018, at India Habitat center, New Delhi, where presented a technical paper on the "significant savings in energy through false air reduction" and received anaward for "upcoming entrepreneur in the field of energy efficiency".
-
14th Green Cementech 2018 held from May 17-18, 2018 at Hyderabad International Convention Center, Hyderabad where presented technical paper on "Enhancing Energy efficiency in Captive Power Plants by reduction of False Air".
Some of our articles also published in CMA’s Technical Journal "Cement Energy & Environment", Vol. 17 No. 1 (Jan – Jun 2018) & Vol. 18 No. 1 (Jan – Jun 2019).
Invotech Industrial Solutions has recently developed a product called Arrest Master ABS for enhancing energy efficiency. It can be used to cool down the area rapidly with less air consumption but gives output 7 to 8 times as compared to normal air consumption. It is a special design Nozzle, works on Coanda Effect. Arrest Master ABS uses little amount of compressed air to deliver high volume output. Arrest Master ABS, a compressed air boost device, has been designed to give trouble free & maintenance free service as there is no moving part in it.It can also be used to cool down bearing housing, cutting hot material, cooling of lathe machine jobs etc.
Product highlights of Arrest Master ABS:
- Energy efficient device
- Provides efficient cooling
- User friendly and ready-to-use modules
- Easy installation and relocation
Conclusion
Substantial potential for energy efficiency improvement exists in the cement industry and in individual plants. Persistent efforts are also being made to continue to improve energy efficiency and reduce the energy cost for the cement industry for survival and growth. Our baby step towards arresting "false air" can contribute immensely towards cost cutting of cement manufacturing and improving energy efficiency. It is needless to mention that our efforts to improve energy efficiency will also minimise greenhouse gas and mitigate the environmental problems associated with cement production.
ABOUT THE AUTHOR: KK Sharma is from Invotech Industrial Solutions Near Shivam Hyundai, Parbatpura Industrial Area, Ajmer- 305001, Rajasthan. Tel: 8005521600/9001458666 Email: invotech@invotechsol.com | invotech_ajm@yahoo.com Web: www.invotechsol.com

The Indian cement industry has reached a critical juncture in its sustainability journey. In a landmark move, the Ministry of Environment, Forest and Climate Change has, for the first time, announced greenhouse gas (GHG) emission intensity reduction targets for 282 entities, including 186 cement plants, under the Carbon Credit Trading Scheme, 2023. These targets, to be enforced starting FY2025-26, are aligned with India’s overarching ambition of achieving net zero emissions by 2070.
Cement manufacturing is intrinsically carbon-intensive, contributing to around 7 per cent of global GHG emissions, or approximately 3.8 billion tonnes annually. In India, the sector is responsible for 6 per cent of total emissions, underscoring its critical role in national climate mitigation strategies. This regulatory push, though long overdue, marks a significant shift towards accountability and structured decarbonisation.
However, the path to a greener cement sector is fraught with challenges—economic viability, regulatory ambiguity, and technical limitations continue to hinder the widespread adoption of sustainable alternatives. A major gap lies in the lack of a clear, India-specific definition for ‘green cement’, which is essential to establish standards and drive industry-wide transformation.
Despite these hurdles, the industry holds immense potential to emerge as a climate champion. Studies estimate that through targeted decarbonisation strategies—ranging from clinker substitution and alternative fuels to carbon capture and innovative product development—the sector could reduce emissions by 400 to 500 million metric tonnes by 2030.
Collaborations between key stakeholders and industry-wide awareness initiatives (such as Earth Day) are already fostering momentum. The responsibility now lies with producers, regulators and technology providers to fast-track innovation and investment.
The time to act is now. A sustainable cement industry is not only possible—it is imperative.
Concrete
It is equally important to build resilient building structures
Published
7 days agoon
May 13, 2025By
admin
Manoj Rustagi, Chief Sustainability Officer, JSW Cement, discusses how the adoption of ‘green’ practices in cement manufacturing could reshape the future of sustainable construction worldwide.
Cement is one of the most carbon-intensive materials in construction — but innovation is changing that. As sustainability becomes central to infrastructure, green cement is emerging as a viable low-carbon alternative. In this detailed interview with Manoj Rustagi, Chief Sustainability Officer, JSW Cement, we explore what makes cement ‘green’, its performance, and its future. From durability to cutting-edge technologies, here’s a look at the cement industry’s greener path forward.
What exactly is green cement, and how does it differ from traditional cement?
At this point in time, there is no standard for defining green cement. A very simple way to understand ‘Green Cement’ or ‘Low Carbon Cement’ is the one which emits much lower greenhouse gasses (GHG) compared to conventional cement (Ordinary Portland Cement – OPC) during its manufacturing process.
In India, there are many existing BIS Standards for different types of cement products. The most common are OPC; Portland Pozzolana Cement (PPC); Portland Slag Cement (PSC) and Composite Cement (CC). While OPC emits maximum GHG during its manufacturing (approx 800-850 kg CO2/MT of OPC), PSC emits least GHG (approx 300-350 kg CO2/MT of PSC). As PSC is having close to 60 per cent lower CO2 emission compared to OPC, it is the greenest cement available in the Indian market.
There is already work happening at the central government level to define green cement, like it has been recently done for green steel, and hopefully in the next one year or so the standard definition would be available.
What are the key environmental benefits of using green cement?
The primary environmental benefits of green or low-carbon cement are:
- Reduced CO2 emissions
- Lower energy and power consumption
- Conservation of limestone and fossil fuels
- Utilisation of industrial by-products
- (slag/fly ash)
Can green cement match the durability and strength of conventional cement?
PSC is much more durable than any other type of cement product. It has lower heat of hydration; the strength keeps on improving with time; and it has much higher resistance to chloride and sulphate attacks. Most of the concrete failures are because of chloride and sulphate attacks, which corrode the steel reinforcements and that is how cracks get initiated and propagated resulting in eventual concrete failures. For coastal applications, marine structures, seaports, and mass concreting, PSC is most suitable. Due to the intrinsic durability characteristics of PSC; it is a green and resilient cement product.
Usually everyone talks about lower GHG emissions, but it is equally important to build resilient building structures that can withstand natural calamities and have much longer lifespans. PSC is one cement type that is not only lowest in CO2 emissions but at the same time offers durability characteristics and properties (RCPT, RCMT, Mercury Intrusion, long term strength and flexural strength), which are unmatched.
What innovative technologies are being used to produce green cement?
To further reduce the CO2 emissions in the manufacturing process; some of the innovative technologies which are commercially viable are:
- Alternative raw materials: Use of steel slag, red mud and other industrial by-products to substitute limestone
- Alternative fuels: Use of RDF/MSW, pharmaceutical wastes like biomass etc., to substitute coal/pet-coke
- Waste Heat Recovery (WHR): Power plants to generate electricity from waste heat
- Renewable energy: Solar and wind energy instead of state grid
How cost-effective is green cement compared to traditional options?
All of the above innovative technologies do not increase the cost of manufacturing. There are some future technologies like Carbon Capture, Utilisation and/or Storage (CCUS), which are not commercially viable and would increase the cost of cement. As such, the options available today for low-carbon cement (like PSC) are not expensive.
The Government of India has recently notified Indian Carbon Market (ICM), which also includes the cement sector. Hopefully, this would help progressive companies to further reduce their carbon footprint.
What challenges does the industry face in adopting green cement on a large scale?
There is absolutely no incentive/motivation for builders/contractors to use green cement products and therefore there is practically no demand. While the industry has taken many steps. In fact the Indian cement industry is believed to be most energy efficient globally and has approximately 10 per cent lower GHG emissions compared to global average. But due to lack of awareness and lack of performance based standards; the demand for low carbon cement or green cement has not picked up in India.
Are governments and regulators supporting the shift to green cement?
In India, in the last couple of years, there have been many policy interventions which have been initiated. One of them, namely the carbon market is under notification; others like Green Public Procurement, Green Cement taxonomy and National CCUS Mission are in the advanced stages and are expected to be implemented in the next couple
of years.
How do you see the future of green cement in global construction?
Globally the built environment accounts for 40 per cent CO2 emissions; and the maximum embodied emissions come from cement and concrete. There is a lot of innovation happening in cement, concrete and construction. Basically, how we build and what material we use. And this is to do with both carbon mitigation as well as adaptation as the built environment is so important for sustainable living. Precast and pre-engineered buildings/structures, 3D concrete printing, ultra high performance concrete, digital and AI/ML interventions in construction, admixtures/improved concrete packing; and circularity in cement manufacturing are some examples. Low-carbon cement or green cement eventually will lead to ‘Net Zero CO2 emission’ cement, which would enable a ‘Net-Zero’ built environment that is needed for long term sustainability.

Milind Khangan, Marketing Manager, Vertex Market Research, looks at how India’s cement industry is powering a climate-conscious transformation with green cement at its core, aligning environmental urgency with economic opportunity.
The cement industry produces around eight per cent of the world’s total CO2 emissions. Process emissions, largely due to limestone calcination, contribute 50 to 60 per cent of these emissions and produce nearly one ton of CO2 per ton of cement produced.
India is a leading cement producer with an installed capacity of around 550 million tons (MMT) as of 2024. As the Government of India advances toward its 2070 net-zero target, green cement is becoming a major driver of this shift toward a low-carbon economy. It offers environmental sustainability as well as long-term operating efficiencies at scale. With the fast-paced urbanisation and infrastructure development across the nation, the use of green cement goes beyond environmental imperatives; it is also a strong strategic business opportunity. Indian cement players are some of the most sustainable and environmentally conscious players in the world, and indigenous cement demand in India is estimated to grow at a CAGR of 10 per cent until 2030.
Innovating sustainably
Green cement is an umbrella term that includes multiple advanced technologies and processes aimed at minimising the environmental footprint, and CO2 emissions of conventional cement manufacturing. This shift from traditional practices targets minimising the carbon footprint throughout the whole cement manufacturing process.
- Clinker substitution: Substitution of high-carbon clinker with supplementary cementitious materials (SCMs) in order to considerably lower emissions.
- Alternative binders: Developing cementitious systems that require minimal or no clinker, reducing reliance on traditional methods.
- Novel cements: Introducing new types of cement that depend less on limestone/clinker, utilising alternative modified processes and raw materials.
- Energy efficiency and alternative fuels: Optimising energy utilisation in production and substituting fossil fuel with cleaner alternatives coming from waste or biomass.
- Carbon capture, utilisation, and storage (CCUS): Trapping CO2 emissions at cement plants for recycling or geological storage.
Drivers and strategic opportunities
Robust infrastructure development pipeline: The government’s continued and massive investment in infrastructure (roads, railways, housing, smart cities) generates huge demand for cement. Crucially, there is a growing preference and sometimes direct requirement under public tenders for sustainable building materials, including green cement, which is giving a significant market stimulus.
India’s national climate commitments (NDC and Net Zero 2070): India’s commitments under the Paris Agreement (NDCs) and the long-term goal of achieving Net Zero emissions by 2070 have set a clear direction for industrial decarbonisation. This national strategy necessitates action from high-emitting sectors such as cement to adopt green cement technologies and carbon-reducing innovations across the construction value chain. Notably, the Indian cement industry alone is expected to generate nearly 400 million tonnes of GHG emissions by 2030.
Regulatory mandates for fly ash utilisation: The Ministry of Environment, Forest and Climate Change (MoEFCC) has released a number of binding notifications that promote the use of fly ash from thermal power plants. These guidelines seek to reduce environmental impact by enhancing its extensive application in cement production, particularly in Portland Pozzolana Cement (PPC). Fly ash acts as a pozzolanic material, reacting with calcium hydroxide to produce cementitious compounds, hence decreasing clinker consumption, a high-energy component contributing to high CO2 emissions. Through clinker substitution facilitation, such mandates directly enable the production of low-carbon green cement.
Promotion and utilisation of blast furnace slag: Steel plant slag utilisation policies provide a ready SCM for manufacturing Portland Slag Cement (PSC). This is advantageous in terms of the supply of another key raw material for green cement manufacturing.
Increased demand due to green building movement
The larger adoption of green building codes and certification systems such as GRIHA and LEED India by builders and developers promotes the use of materials with reduced carbon content. Cement products with a higher SCM content or produced through cleaner processes are preferred. A step in this direction was achieved in October 2021 when Dalmia Cement achieved the distinction of being the first Indian cement producer to be granted the Green Product Accreditation of GRIHA.
The Indian industry is actively investing in R&D for new binders such as geopolymer cement, alkali-activated materials and limestone calcined clay cement (LC3). Research institutions including IIT Madras are collaborating with industry to scale these technologies. Although Carbon Capture, Utilisation, and Storage (CCUS) is still at a nascent stage in India, it represents a potential frontier for long-term decarbonisation in the cement sector.
The MoEFCC has published draft regulations under the Carbon Credit Trading Scheme (CCTS), 2023, in the form of the Greenhouse Gas Emission Intensity Target Rules, 2025. The draft notification requires 186 cement units in India to lower their GHG emission intensity from FY 2025-26. Non-compliant manufacturers will have to purchase carbon credit certificates or face penalties, creating a clear regulatory and financial incentive to adopt cleaner technology. The CCTS will promote technology and practice adoption that reduces the carbon intensity of cement manufacturing, potentially resulting in the use of green cement and other low-carbon substitutes for cement.
India’s leading cement companies like UltraTech, Shree Cement, and Dalmia Bharat have made science-based targets and net-zero emissions pledges in line with the GCCA 2050 Cement and Concrete Industry Roadmap. These self-declarations are hastening the shift towards clean cement manufacturing technology and renewable energy procurement.
Challenges and complexities in India’s green cement transition
Economic viability and cost challenges: High production costs associated with low-carbon cement technologies remain a significant hurdle. The absence of strict carbon pricing and poor financial incentives slow down rapid uptake on a large scale. Although green cement is currently costlier than conventional options, greater market adoption and scale-driven efficiencies are expected to progressively narrow this price gap, enhancing commercial viability over time. As these technologies mature, their broader deployment will become more feasible.
Inconsistent supply chain of SCMs: A dependable supply of high-quality Supplementary Cementitious Materials (SCMs), such as fly ash and slag, is crucial. But in the course of decarbonisation of India’s power generation and industry sectors, SCMs reliability and availability may become intermittent. Strong, decentralised logistics and material processing units must be developed in order to provide uninterrupted and economical SCM supply chains to cement producers.
Gaps in technical standards and performance benchmarks
Although PPC and PSC are well-supported by existing BIS codes, standards for newer materials such as calcined clay, geopolymer binders and other novel SCMs require timely development and updates. Maintaining steady performance, lasting robustness, and usage dependability in varying climatic and structural applications will be key to instilling market faith in other forms of cement formulation. Market stakeholders are also supporting separate BIS codes for the green cement sub-categories for helping to build and sustain standardisation and trust.
Scaling of emerging technologies
Scaling promising technology, especially CCUS, from pilots to commercial scales within the Indian context involves significant investment of capital, technical manpower, and a facilitating regulatory environment. The creation of infrastructure for transportation and long-term storage of CO2 will be critical. While these facilitative systems are implemented, cement makers will be well-placed to decarbonise their operations and achieve national sustainability goals.
The way ahead
The Indian cement industry is poised to enter a revolutionary era, where decarbonisation and sustainability are at the heart of expansion. Industry players and the government need to join hands in an integrated manner throughout the cement value chain to spearhead this green revolution. Cement companies must embrace new technologies to lower the emissions like the utilisation of alternative fuels like biomass, industrial wastes, and recycled materials and utilisation of waste heat recovery systems to make energy efficient. The electrification of logistics and kilns, investigation of high-heat alternative products, and CCUS technology investments must be made to decarbonise production. Sophisticated additives such as polymers can improve cement performance with reduced environmental footprint.
At the policy level, the government has to introduce support measures such as stable carbon pricing, tax relief, viability gap funding, and initiatives such as the PLI scheme to encourage the use of renewable energy in cement manufacturing. Instruments such as carbon contracts can stabilise carbon credit prices and reduce market risk, encouraging investment in low-carbon technologies. Updating BIS standards for newer green cement formulations and SCMs is also critical for market acceptance and confidence. Green cement mandates in public procurement and long-term offtake contracts have the potential to generate stable demand, and green financing windows can guarantee commercial viability of near-zero carbon technologies. Cement greening is not a choice, it is a necessity for constructing a climate-resilient, sustainable India.
About the author:
Milind Khangan, Marketing Manager, Vertex Market Research, comes with more than five years of experience in market research and lead generation. He is responsible for developing new marketing plans and innovations in lead generation, having expertise in creating a technically strong website that generates leads for startups in market research.
