Microgrids can transform cement plant energy sourcing

Published

6 months ago

September 10, 2025

admin

Dr Avijit Mondal, Deputy General Manager (DGM), NTPC Energy Technology Research Alliance (NETRA), NTPC, explains in detail how power sector innovations are opening new frontiers for energy-intensive industries like cement.

As the cement sector seeks pathways to efficiency and decarbonisation, lessons from the power sector—particularly thermal and renewable energy research—are becoming indispensable. Dr Avijit Mondal, Deputy General Manager, NTPC Energy Technology Research Alliance (NETRA), NTPC, shares how innovations ranging from microgrids and biomass co-firing to CO2-to-methanol pilots and CFD modelling are reshaping cement plant energy sourcing. In this conversation, he outlines a roadmap where power plant technologies and cement operations converge to deliver cleaner, more reliable and cost-efficient production.

How does research in thermal power plants drive energy efficiency for heavy industrial loads such as cement?
Cement is India’s second-largest industrial power consumer, and every kilowatt-hour saved or sourced from cleaner energy directly lowers the cost of clinker production. Research and development in thermal power plants (TPPs) plays a critical role in achieving these gains, delivering benefits through high-efficiency generation, flexible operation, improved power quality and integrated carbon management. Most importantly proper combustion in boilers (thermal power plants) creates good quality fly ash (bottom ash), which is an important raw material for the cement industry.
Advancements such as supercritical and ultra-supercritical steam cycles, improved turbine designs and auxiliary systems with variable frequency drives on feedwater, induced-draft, and forced-draft fans lower heat rates by 1.5 per cent to 3 per cent, reducing both grid emission factors and delivered tariffs-especially during off-peak hours. Ultra-low-load stable operation enables cement plants to shift energy-intensive processes such as finish grinding and mine operations to off-peak night hours, reducing power costs. R&D in coal-quality handling-using on-belt analysers and AI-driven blending-enhances steam generator stability, reducing ramp losses and improving heat rates, which in turn minimises power price volatility for industrial users.
Power quality research, including stat-coms, synchronous condensers and harmonic filters, stabilises voltage and frequency for large drives, reducing motor losses, tripping incidents and rework in cement operations. Flexible load management and industrial demand response strategies co-developed with utilities-such as automated compressor/crusher set-backs and ‘grind-at-night, burn-by-day’ schedules-help align cement energy use with renewable-rich periods. On the thermal side, TPP waste-heat recovery concepts, air preheaters and regenerative exchangers have been adapted for cement kilns, enabling exhaust gas recovery for process heat or captive power.
Parallel work in low-NOx combustion, biomass co-firing and fuel preparation optimises kiln firing efficiency, while digitalisation and predictive analytics, pioneered in TPP operations, enhance process control, maintenance scheduling, and energy loss detection in cement plants. Cogeneration models allow direct supply of steam or heat from nearby TPPs, and joint carbon capture and utilisation research offers pathways to mineralise captured CO2 in cement or use it in curing, further reducing emissions.
The combined effect of these interventions is substantial: incremental heat-rate improvements alone can lower grid CO2 intensity by 20-40 g/kWh, while smart time-of-use alignment can cut plant power costs by 2 per cent to 4 per cent. Together, these innovations lower specific energy consumption, improve process stability, and make cement manufacturing more cost-competitive and sustainable.

What innovations in microgrids or Solar/BESS could benefit cement power sourcing microgrid architecture for cement?
Cement manufacturing is among the most energy-intensive industrial processes, with continuous high loads from kilns, grinding mills, crushers and conveyors. Integrating a hybrid behind-the-meter microgrid offers a powerful solution to improve energy efficiency, reduce power costs, and enhance operational resilience. A typical integrated cement plant can deploy a hybrid system comprising 8-15 MWp of rooftop and ground-mounted solar PV, 8-25 MW of waste heat recovery (WHR) capacity, and a Battery Energy Storage System (BESS) sized for 15-30 minutes of peak plant load. In this configuration, solar PV supplies the daytime base load for processes like grinding and material transport, WHR delivers steady baseload power for kiln and cooler exhaust, and BESS handles ramping and flicker control. The BESS also enables peak shaving during kiln starts or crusher surges, provides frequency and VAR support to safeguard large variable frequency drives (VFDs), smooths renewable fluctuations to stabilise kiln induced-draft (ID) control, and offers black-start capability for captive power systems.
The system is coordinated by an advanced Energy Management System (EMS) with process awareness. This EMS forecasts solar generation and plant load, dynamically reschedules non-critical operations such as mills, packing lines and mine conveyors into solar-rich periods, and isolates the kiln and calciner from disturbances. It can also manage load shifting strategies, such as ‘grind at day, burn at night,’ aligning with renewable-rich grid periods.
Recent innovations in industrial-scale BESS include long-duration storage (4-8 hours) to cover full or partial shifts on solar and WHR, and high-C-rate batteries capable of handling sudden restarts or process surges. Some plants also deploy DC-coupled PV + BESS configurations, which reduce inverter losses and improve round-trip efficiency compared to AC-coupled systems. Capturing curtailed renewables by storing excess solar or wind energy in BESS or using it for low priority loads such as precursing further enhances system value.

Supporting infrastructure includes microgrid-ready switchgear and fast-transfer/static breakers to enable seamless islanding from the grid without tripping large motors. The architecture supports multiple operating modes:

Grid-Connected Optimised Mode: Minimises grid draw during peak tariff hours.
Island Mode: Operates on WHR + Solar + BESS during grid outages.
Peak Shaving Mode: Uses BESS to offset short-term spikes, reducing demand charges.
Load Shifting Mode: Aligns high-energy processes with solar availability.

Impact: Field implementations show 18 per cent to 28 per cent reductions in grid imports, 3 per cent to 6 per cent lower specific power costs, improved power quality (fewer nuisance trips), and measurable gains in kiln uptime. By combining solar, WHR, storage and intelligent control, microgrids can transform cement plant energy sourcing into a cleaner, more reliable and more cost-effective system.

How does a flue-gas CO2-to-methanol pilot translate to process efficiencies?
A flue-gas CO2-to-methanol pilot can translate into process efficiencies for both power plants and the cement industry in ways that go beyond just making methanol-it can also improve energy utilisation, plant integration and operational flexibility.

Here’s the breakdown in context:

A. Productive Use of a Waste Stream

Traditional: Flue gas CO2 is a liability-needs to be vented or captured and stored, consuming energy without direct revenue.
With CO2-to-Methanol: CO2 becomes a feedstock for a value-added product (methanol), effectively monetising a waste stream.
Efficiency Link: This improves the overall resource efficiency of the plant because the carbon in the fuel/raw material is not wasted but transformed into a marketable chemical.

B. Integration with Heat and Power Flows

The hydrogen for methanol synthesis (via water electrolysis) requires significant electricity, ideally from renewable or low-cost surplus power.
In power plants: The process can use low-grade waste heat from turbines or economisers to preheat CO2/H2 streams, reducing compression and reaction energy.
In cement plants: Kiln and clinker cooler waste heat can play the same role, allowing higher overall thermal efficiency without disrupting clinker production.

C. Smoothing Power Plant Load and Improving Capacity Factor

Electrolysers for H2 production can act as a flexible load:
Ramp up when grid demand is low or renewable generation is high.
Ramp down when power demand is high.
Benefit for TPPs: Reduces the need for inefficient low-load operation and enables steadier turbine efficiency.

Benefit for cement plants: If tied to an on-site WHR + PV/BESS microgrid, it can soak up excess renewable/WHR power during low cement demand periods.

D. Synergy with Flue Gas Conditioning

The CO2 capture step for methanol production often includes flue gas cleaning (removing SOx, NOx, particulates).
This upgrades the quality of flue gas, which can reduce corrosion/fouling in downstream WHR boilers, improving plant availability and heat recovery efficiency.

E. Reduction in Carbon Intensity

Power sector: Each tonne of CO2 converted to methanol lowers net emissions, improving compliance with carbon pricing or emission norms.
Cement sector: Reduces CO2 intensity per tonne of clinker by diverting a portion of process emissions into methanol synthesis.

F. Methanol as a Circular Energy Carrier
The methanol produced can be:

Sold as a chemical feedstock or marine fuel.
Used internally in dual-fuel boilers/turbines for backup power.

This creates an energy loop-CO2 captured from flue gas ? methanol ? reconverted to energy when needed, improving energy storage and fuel flexibility.

Can biomass co-firing methods from power plants be customised for cement kilns?
Yes-adaptation is practical, with kiln-specific care:

Transferable learnings from utility co-firing

Feedstock prep: Size reduction, torrefaction/pelletising, moisture control ? stable feeding through calciner/kiln burners.
Metering and pneumatics: Proven dosing/air-assist systems maintain steady thermal input and flame shape.
Chlorine/alkali management: Power-plant protocols for fuel qualification apply directly; in cement, they also protect clinker quality and rings.
Cement-specific customisations
Burner tuning: Biomass raises volatiles and lowers flame temperature; adjust primary/secondary air, swirl, momentum to avoid over-penetration or CO spikes.
Ash chemistry: Track K2O/Na2O/Cl and P2O5 to manage coating and alite formation; limit certain agri residues unless pre-leached or blended.
Where to fire: Higher substitution is often easier in the calciner than main burner; start 10 per cent to 20 per cent TSR in calciner, step up with monitoring.
Outcomes: 15 per cent to 35 per cent thermal substitution is realistic with prepared biomass; 1 per cent to 4 per cent specific heat consumption (SHC) reduction from improved combustion stability and moisture trimming.

How does CFD modelling optimise combustion for lower fuel use and emissions?
Computational Fluid Dynamics (CFD) has emerged as an indispensable tool for optimising energy efficiency, combustion stability, and emissions control in cement manufacturing. By simulating the three-dimensional flow dynamics and combustion chemistry inside the kiln, calciner, tertiary air ducts, and burners, CFD provides a deep, visual understanding of how gases, fuels and solids interact. These insights enable targeted design improvements and operational fine-tuning, ultimately reducing energy consumption and extending equipment life.
Design and operational applications. CFD modelling allows engineers to evaluate and optimise critical parameters including:

Burner Quarles and Jet Geometry: Adjusting jet angles, swirl intensity, and momentum ratios for ideal flame characteristics.
Airflow Distribution: Balancing secondary and tertiary air splits to match process demand.
Calciner Staging: Sequencing combustion zones to maximise calcination efficiency.
SNCR/AFR Injection Points: Locating selective non-catalytic reduction systems and alternative fuel inlets for optimal mixing and burnout.

Efficiency and performance levers are identified through CFD

Burner Optimisation: Tailoring swirl and jet momentum to create a narrower, elongated flame enhances heat transfer to the kiln bed, delivering a 0.5 per cent to 2 per cent reduction in specific heat consumption (SHC).
Optimised Calciner Staging: Achieving complete calcination at reduced excess air levels cuts NO emissions by 15 per cent to 30 per cent while avoiding the energy penalties of over-firing.
Hot-Spot Mitigation: Detecting and eliminating localised high-temperature zones prevents ring formation and coating build-ups, extending refractory life and improving uptime-a significant indirect energy saving.
Strategic AFR Placement: Injecting late-volatile alternative fuels in zones with the right oxygen and temperature balance avoids CO spikes and unburnt fuel losses.

The power of CFD lies not only in simulation but also in validation and integration. Best practice involves confirming model predictions through on-site measurements, including kiln hood and calciner thermography, CO/NOx traverses, and clinker microscopy. Once validated, these insights can be locked into operations using Advanced Process Control (APC) systems, ensuring consistent, long-term efficiency gains.

What role will hydrogen technologies play in decarbonising heavy industries?
Near-term actions (0-5 Years)

Hydrogen Enrichment of Burners (5 per cent to 20 per cent): Enhance flame stability and precision, enabling higher biomass and alternative fuel (AFR) substitution without incurring CO emissions penalties.
Green Oxygen Integration: Use oxygen generated from electrolysers to reduce excess air requirements and achieve better stoichiometric control, lowering NOx formation.
Power-to-Heat Applications – Deploy electro-boilers and electric dryers for plant auxiliaries in solar-rich regions, freeing up fossil-fuel-derived heat for the kiln.
Medium-term actions (5-10 Years)
Hydrogen-Ready Burners: Install kiln and calciner burners designed for high hydrogen blends, with ammonia used as a hydrogen carrier and cracked near the point of use.
E-Fuels Co-Firing: Incorporate e-methanol or e-syngas to provide dispatchable, low-carbon thermal energy.

How are ash or waste-heat recovery (WHR) technologies from power plants applicable to cement production?
Ash utilisation

Fly Ash in Blended Cements (PPC/PSC): Substituting 25 per cent to 35 per cent clinker with fly ash significantly reduces thermal load and CO2 intensity. Performance depends on Loss on Ignition (LOI), fineness, and phase composition; selectively harvested dry-silo ash offers the most consistent quality.
Bottom Ash / Pond Ash: Usable in certain
products after classification and grinding, though attention is needed to control unburnt carbon and contaminants.
FGD Gypsum: Flue Gas Desulphurisation gypsum from power plants provides a dependable alternative to natural gypsum for setting regulation.

Waste heat and power integration
• Cement WHR Systems: Using AQC/SP boilers with steam turbines or Organic Rankine Cycle (ORC) units typically recovers 20-35 kWh/t clinker. Best practice involves applying utility pinch-analysis learnings, controlling fouling,
and optimising condenser pressure for uptime and efficiency.
• Cross-Industry Synergies: Co-location with power plants enables use of their low-grade heat (or CO2 capture waste heat) for pre-drying alternative fuels or raw mix; conversely, WHR output from cement plants can supply auxiliary loads during grid peak demand.
• Circular Economy Benefits: Combining ash and FGD gypsum utilisation closes the mineral loop, while WHR and low-grade heat recovery close the energy loop-together lowering Specific Heat Consumption (SHC) and Scope 1 and 2 emissions.
A practical 6-step roadmap for cement plants
• Step 1: Energy Mapping and Pinch Analysis: Assess kiln, calciner, mills, and auxiliaries to identify 1 per cent to 3 per cent SHC savings.
• Step 2: CFD and Advanced Process
Control: Optimise burner, calciner, and AFR injection points for improved efficiency and emissions control.
• Step 3: Solar-WHR-BESS Microgrid: Implement process-aware Energy Management Systems to achieve 15 per cent to 20 per cent peak-shaving.
• Step 4: Biomass/AFR Scale-Up: Apply fuel-lab testing protocols to safely reach 20 per cent to 30 per cent Thermal Substitution Rate (TSR) in the calciner first.
• Step 5: CO2-to-X Pilots: Integrate heat
cascade systems and O2 reuse where green power is accessible.
• Step 6: Power-Sector Partnerships: Secure agreements for deep-turndown tariffs, power-quality guarantees, and consistent Class-A fly ash and FGD gypsum supply.

With contribution from Dr Gaurav Richhariya,
Executive R&D (Ash Technology), NTPC Energy Technology and Research Alliance (NETRA), NTPC.
